A SINAMICS G120 drive is used as a speed axis and is controlled with a SIMATIC S7-1200 with the “SINA_SPEED” block.

A PROFINET-capable SINAMICS G120 drive is to be controlled via a SIMATIC S7-1200. The setpoint speed and a direction of rotation is to be specified.

Solution
This application example shows the PROFINET connection of a SINAMICS G120 to a SIMATIC S7-1200 with SINAMICS Startdrive. The drive is controlled with the “SINA_SPEED” block which can be downloaded directly from a standard library in the TIA Portal.

Note
The block "SINA_SPEED" is also be used with a SIMATIC S7-1500 controller.

SIEMENS STARTER SSP SINAMICS G120 V4.7.13 HF3 - SSP_SINAMICS_G120_V4_7_SP13_HF3.zip

SSP, SINAMICS G120 V4.7 SP13 HF3 (V04.71.52.00_06.90.11.06)

With this SINAMICS Support Package, SINAMICS G120/G120C/G120P/G120D drives with firmware version V4.7 SP13 can be configured and commissioned using STARTER or SCOUT.
