; GSD-Datei fuer SFC-DC mit PROFIBUS-DP-Interface (DP-V0)
;----------------------------------------------------------------------------
; Hersteller: Festo AG & Co. KG
; Ruiterstrasse 82
; 73734 Esslingen
; Germany
;
; Festo Hotline: +49 (0)711 / 347 3000
; Download Area: www.festo.com
;----------------------------------------------------------------------------
; 14.12.2005, Gull
; Erste Version nach Zertifizierungstest bei itm in Muenchen
; - MaxTsdr an Profichipempfehlung fuer VPC3+C angepasst.
; - Max_User_Prm_Data_Len = 4
; - Texte in Englisch
; 27.06.2006, Gull
; - Leerzeichen zwischen 'Ext_User_Prm_Data_Const' und '(0)' entfernt
; wegen Problemen bei Beckhoff Steuerung
; 02.08.2007, Gull
; - Firmwareversionen 1.30 - 1.39 in Diagnosedaten ergaenzt
; 30.07.2008, Gull
; - Firmwareversions- und Hardwareversions-Texe aus Diagnosedaten entfernt
;*****************************************************************************
#Profibus_DP
GSD_Revision = 1
;
Vendor_Name = "Festo AG & Co. KG"
Model_Name = "Festo SFC-DC DP-V0"
Revision = "1"
Ident_Number = 0x0973
Protocol_Ident = 0
Station_Type = 0
FMS_supp = 0
Hardware_Release = "V 01.00"
Software_Release = "V 01.10"
;
9.6_supp = 1
19.2_supp = 1
45.45_supp = 1
93.75_supp = 1
187.5_supp = 1
500_supp = 1
1.5M_supp = 1
3M_supp = 1
6M_supp = 1
12M_supp = 1
;
MaxTsdr_9.6 = 15
MaxTsdr_19.2 = 15
MaxTsdr_45.45 = 15
MaxTsdr_93.75 = 15
MaxTsdr_187.5 = 15
MaxTsdr_500 = 15
MaxTsdr_1.5M = 20
MaxTsdr_3M = 35
MaxTsdr_6M = 50
MaxTsdr_12M = 95
;
Redundancy = 0
Repeater_Ctrl_Sig = 2
24V_Pins = 0
Implementation_Type = "VPC3+C"
;
Bitmap_Device = "sfc-dc_n"
Bitmap_Diag = "sfc-dc_d"
Bitmap_SF = "sfc-dc_s"
;
Freeze_Mode_supp = 1
Sync_Mode_supp = 1
Auto_Baud_supp = 1
Set_Slave_Add_supp = 0
Min_Slave_Intervall = 6
Fail_Safe = 0
;
Modular_Station = 1
Max_Module = 1
Max_Input_Len = 16
Max_Output_Len = 16
Max_Data_Len = 32
;
Max_Diag_Data_Len = 20
Modul_Offset = 0
Slave_Family = 1@Festo
;
; <Parameter-Definition-List>
PrmText = 1 ; Referenznummer 1
Text(0) = "Device related diag ON"
Text(1) = "Device related diag OFF"
EndPrmText
;
ExtUserPrmData = 1 "Device related diagnosis" ; Referenznummer 1
Bit(0) 0 0-1 ; Default = 0, Min = 0, Max = 1
Prm_Text_Ref = 1 ; Verweis auf Text-Definition 1
EndExtUserPrmData
;
Max_User_Prm_Data_Len = 4
Ext_User_Prm_Data_Const(0) = 0x00,0x00,0x00
Ext_User_Prm_Data_Ref(3) = 1
;
; <Module-Definition-List>
Module = "FHPP Standard" 0xB7
1
EndModule
;
Module = "FHPP Standard + FPC" 0xB7, 0xB7
2
EndModule
;===================================================
; Diagnosedaten
;===================================================
; Achtung bei der Verwendung von 16-Bit -Arrays
; Hier kommt entgegen der Byteordnung von PROFIBUS
; das Lowbyte zuerst. (liegt an der Bitdefition im
; Diag-Bereich)
;
; Aufbau Gerдtebezogene Diagnose
;
; BYTE 0 Lдnge = 10 Byte
; BYTE 1 Statustype (fix at 0xA0)
; BYTE 2 Slot Number (fix at 0x00)
; BYTE 3 Statusspecifier (fix at 0x00)
; BYTE 4 + 5 Firmware Version
; BYTE 6 + 7 Hardware Version
; BYTE 8 + 9 Stoernummer
;
; Stoernummer
; GbD[7]+GbD[8]
;-----------------------------------------------------
Unit_Diag_Area = 56-71
Value(0) = "No error"
Value(103) = "Motor error"
Value(71) = "Digital power down"
Value(1) = "Please enforce homing run"
Value(2) = "Target position out of limit"
Value(32) = "Homing error"
Value(52) = "Hardware error"
Value(100) = "i2t error"
Value(31) = "Position error"
Value(101) = "Overheating"
Value(106) = "Motor stop"
Value(70) = "Load power down"
Value(51) = "Profibus init error"
Unit_Diag_Area_End |
