INOVANCE PROFINET GSDML FILES

GSDML-V2.31-INOVANCE-GL20-RTU-PN-20240401.xml

GSDML-V2.31-inovance-H5U-20230403.xml

GSDML-V2.31-Inovance-IS620F-RT-20220330.xml

gsdml-v2.33-inovance-is620f-20210415.xml

GSDML-V2.31-inovance-md500-20180705.xml

GSDML-V2.33-Inovance-MD500PN-20200619.xml

GSDML-V2.31-inovance-MD800PNGATE-20220317.xml

GSDML-V2.31-inovance-MD810PNGATE-20180731.xml

Inovance GL10, GR10 XML files.7z

GL10_1600END_3200END_0016XXX_0032ETN_4AD_4DA_4PT_8TC_4TC - GL10-AM600-RTU-ECTA_2.0.6.0.xml

GL10-RTU-COP CANopen EDS - GL10RTU-COP.eds

GR10_2HCE - GR10-AM600-HCE1.2.1.0.xml

GR10_4ADE_4DAE_8TCE - 4ADE_4DAE_8TCE_1.4.5.0.xml

GR10_0808ETNE-1616ETNE - GR10-AM600-0808-1616ETNE1.4.3.0.xml

GR10-AM600-4PME_2PHE - GR10-AM600-4PME_2PHE_1.2.1.0.xml

GR10-EC-3SW_6SW_1.4.2.3 - GR10-EC-3SW_6SW_1.4.2.3.xml

ALL FILES - GSD-GSDML_Inovance.7z - update 09/12/2024

update 20/10/2025 SV660F

GSDML-V2.33-Inovance-SV660F-20220413.xml
GSDML-V2.33-Inovance-SV660F-20240629.xml
GSDML-V2.4-Inovance-SV660F-20240629.xml

GSDML_V233_V24_Inovance_SV660F_20240629.zip

SV660F GSD File Description

V2.33 version : GSDML-V2.33-Inovance-SV660F-20240629.xml

V2.4 version : GSDML-V2.4-Inovance-SV660F- 20240629.xml

Compatibility of GSDML with STEP7 and TIA Portal

Software

Version

V2.33

V2.4

TIA Portal

V13

no

no

V14

yes

no

V15

yes

no

V16

y es

no

V17 and above

yes

yes

STEP 7

V5.5

no

no

V5.6

yes

no

V5.7 and above

yes

yes

Among them: yes-match, no-do not match

Function

Function

V2.33

V2.4

System redundancy

Not supported

support

S7-1200 PROFINET INOVANCE SV660F

Категория: Shenzhen Inovance Technology | Просмотров: 1663 | Добавил: gt7600 | Теги: GSDML, Inovance, PROFINET | Рейтинг: 5.0/1
Всего комментариев: 11
avatar
0
1 agostinho • 17:40, 14.02.2025
Hello!

Does the "GSDML-V2.31-inovance-EASY-20230801.xml" file enable PROFINET communication with INOVANCE Easy 320 PLC?

Thanks!

AO
avatar
0
2 gt7600 • 20:43, 16.02.2025
Hello, agostinho
Yes, you can exchange data via PROFINET.
best regards, Barsukovm

avatar
0
3 Sakumzi99 • 16:51, 08.06.2025
Hi everyone, does anyone have GSDML file for Innovance MD520 AC drive, could you please share for me.
avatar
0
4 gt7600 • 17:47, 08.06.2025
Hi, Sakumzi99
For 520 you can use 500 series gsdml  - GSDML-V2.31-inovance-md500-20180705.xml
avatar
0
5 Sakumzi99 • 19:15, 08.06.2025
thank you @gt7600, I am unable to download this file. when clicking to it, it opens up a new webpage.
avatar
0
6 gt7600 • 19:17, 08.06.2025
Click right button of mouse on link - choose save data on link.
avatar
0
7 Hybrid • 12:37, 22.07.2025
Hi @gt7600
Can you please share these gsdml files "HW.GSD.gsdml-v2.25-festo-cpx-20110809.xml" and "GSDML-V2.3-Siemens-  Sinamics G120  -20111221"
avatar
0
8 gt7600 • 12:48, 22.07.2025
Hello.
1) FESTO i have another versions - https://asutp.org/news/gsdml_festo_cpx_profinet/2023-02-13-103
2) for G120 yo can create gsdml file by VFD using memory card.
avatar
0
9 gt7600 • 13:20, 22.07.2025

Create GSDML by memory card into converter.
avatar
0
10 Andrews • 10:01, 20.10.2025
Hello, does anybody have gsdml-v2.33-inovance-sv660f-20220413.xml?
Share please
avatar
0
11 gt7600 • 19:47, 20.10.2025
Доброго вечера.
GSDML-V2.33-Inovance-SV660F-20220413.xml
GSDML-V2.33-Inovance-SV660F-20240629.xml
GSDML-V2.4-Inovance-SV660F-20240629.xml

GSDML_V233_V24_Inovance_SV660F_20240629.zip
